Hydraulic Hollow Jack
Hydraulic Hollow Jack
Our Hydraulic Hollow Jack offers precise and powerful lifting capabilities, ideal for applications requiring central access. With its robust design and high-pressure hydraulic system, it provides reliable performance.
Key Features
- Central hole design for cable or rod passage
- High lifting capacity
- Precise hydraulic control
- Compact and durable construction
Applications
- Cable pulling and tensioning
- Bridge construction and maintenance
- Heavy machinery installation
- Pre-stressed concrete applications
Benefits
- Increased precision and control
- Enhanced safety and efficiency
- Reduced risk of damage to surrounding components
- Improved productivity
| Double Acting Hydraulic Hollow Jack | ||
|---|---|---|
| Cylinder Type | Welded / Tie Rod type | |
| Return Type | Hydraulic / Gravity / Spring | |
| Bore Size | 50 / 80 / 100 / 125 / 150 / 200 | |
| Rod Size | 30 / 50 / 60 / 75 / 100 / 120 | |
| Stroke Length | 50 mm to 2000 mm | |
| Tested Pressure | 400 bar | |
| Cushion Stroke | 10 mm to 100 mm | |
